TLC

Benefits:
  • Compact design
  • Rigid and stable
  • Plug and play
  • Silent
Features:
  • Push or pull load
  • Low noise level
  • Robust
  • Medically compliant with IEC 60601-1

The TLC series is a compact, fast and powerful range of lifting columns with AC motors for compression and tension loads up to 4,000 N. They are ideal for medical, industrial and workplace applications and can lift off-centre loads without bending thanks to their rigid aluminium profiles and precision sliding cushions. Its unique and efficient gear technology provides high compressive strength and low noise performance.

Product tab contents

Technical Data

Sub tab

Overview
Push load

4 000 N

Pull load

4 000 N

Max stroke (mm)

100 to 700 mm

Voltage

120
230 V AC

Operating temperature

+10 to +40 °C

Type of protection

IP 20 or 30

Max. linear speed no load (mm/s)

up to 11 mm/s

Duty cycle (%)

10

Dynamic offset load

Up to 2 100 Nm

2D / 3D

Warning Message

For product orders, please refer to our catalogue pages where the ordering keys are indicated. Please do not use the ordering keys generated here as they may be incomplete.

Publications
IL-05002/6-EN-September 2022 Actuator range
IL-07010/2-EN-November 2021 TLC
TC-08010-EN-March 2020 TLC operating manual
EL-02003-EN-November 2019 Safety and reliability in motion
